Ceramic pump grout for sale for environmental preservation project


   Gaodetec ceramic grout pump is driven by hydraulic double cylinders and double function, the flow very stable, so be widely used for environmental protect projects, such as Printing and dyeing industry wastewater, sewage wastewater treatment, mechanical processing industry wastewater, electroplating industry waste water, the chemical industry wastewater treatment.


The ceramic grout pump with following features:
1, high work pressure with little undulate/jerks/kicks;
2, simple structure, steady running, lowing noisy, reliable work,
3, easy to operate with long work life, and low maintenance cost
4, compact size, suitable for harsh environ
According to pressure and flow difference, Gaodetec ceramic grout pump has many types for option:
Type
Flow Range
M3/h
Pressure range
Bar
Stroke
MM
Oil Pump Type
Motor
Power KW
Dimension
L*H*W
mm
Weight
YB50-07
0-0.8
0-23
170
GBG-2016
2.2
1200*850*1200
160
YB85-2.5
0-2.5
0-23
170
GBG-2016
4.0
1300*850*1200
280
YB120-7.1
0-7.2
0-25
220
GBG-2050
7.5
1630*1070*1860
750
YB140-10
0-10.5
0-25
230
GBG-2063
11
1630*1120*1900
850
YB200-20
0-22
0-20
240
GBG-2080
18.5
1820*1280*2100
1250
YB250-30
0-32.4
0-20
250
GBG-2080
22
1950*1480*2250
1500
YB300-40
0-42
0-20
250
CEF-F690
30
2150*1650*2450
2300


If have industry wastewater need to be treated, send your inquiry and demands to info@gaodetec.com +86-15903613994 for more suitable type and the best price.

Of course, if have any question on the ceramic grout pump, also please contact us without any hesitation, because we are professional on ceramic grout pump, more better solution will be offered to you at first time.

Contact us now for more information for your grouting business now!!!
